MCX3 ULTRA 2.2KW SPINDLE
from $5,500.00
lead time is 4-6 Weeks
Computer:
Spindle Motor:
Enclosure:
Cutting Lubrication:
Quantity:
lead time is 4-6 Weeks
lead time is 4-6 Weeks
FEATURES
Flood coolant capable
4th axis capable
PlanetCNC TNG software
Mini Windows 10 computer 64GB storage 4GB RAM (keyboard, mouse, and monitor not included)
Epoxy granite frame with Exceptional Dampening
C7 Double Nut Ball screws
Homing switches
Saunders universal tooling plate ready
SPECIFICATIONS
TRAVELS
X-Axis Travel 13"
Y-Axis Travel 7"
Z-Axis spindle to table max distance 9"
SPINDLE (2.2Kw)
Maximum Speed 12,000 RPM (2.2kw)
Maximum Speed 24,000 RPM (2.2kw)
MACHINE SPECIFICATIONS
Table Size 23.75" x 6.3"
M8 Threaded Work Table
500lb typical sytem weight
OVERALL DIMENSIONS
Width 32"
Depth 36"
Height 36"
POWER REQUIREMENT
Single-Phase 220 Vac, 146A breaker
